KX-K Pulse fiber laser marking machine (Raycus laser source)

KX-K Pulse fiber laser marking machine (Raycus laser source)

$2,310.00

Available

The KX-K sub-series uses Raycus’ Q-switched pulsed fiber laser source.This laser source is an industrial-grade marking and micro-machining laser series developed by Raycus. It has high peak power, high single pulse energy, and spot diameter optional features, Its performance in marking applications is more stable than traditional lasers. The KX-K sub-series uses Raycus’ Q-switched pulsed fiber laser source. Product...

Qty:

Category: laser marking machine laser marking machine - Benchtop laser marking machine laser marking machine - Benchtop laser marking machine - Fiber benchtop laser marking machine Vendor: MAC laser

Description
Additional Information

The KX-K sub-series uses Raycus’ Q-switched pulsed fiber laser source.

Product Description

The KX series fiber laser marking machine of Mac Laser is an all-round marking equipment. Because of its strong adaptability, low maintenance and no consumables during the marking process, it is often used in the metal and plastic processing industries.

Fiber series products use 1064nm wavelength laser, which is suitable for various metal materials such as iron, copper, aluminum, gold, silver, and some non-metal materials such as PC, ABS, PVC, PC+ABS. It is widely used in 3C, auto parts, electronic components, integrated circuits (PC), electrical appliances, precision equipment, hardware products, building materials, clocks and watches, jewelry, craft gifts and other industries.

>> Appearance: integrated cabinet, small footprint;
>> Performance: It has perfect laser characteristics and good pulse shape control ability. The seed source adopts waveform compensation, the amplified pulse deformation is corrected, and the output pulse energy is higher;
>>  Control: use industrial computer with keyboard, mouse and LCD, similar to desktop computer operation mode, application is simple, safe, accurate and easy to use;
>>  Software: Full English interface based on Windows system, convenient for daily application, intuitive content;
>>  Service: This series of marking machines are flexible and easy to operate. Mac laser provides reliable after-sales service to ensure your use needs.

Scope of application

Product Parameter

Model Series	KX-K sub-series (Raycus laser source)
Model	KX-200K	KX-201K	KX-300K	KX-301K	KX-500k	KX-600k	KX-700k	KX-1000K
Laser Model	RFL-P20QS	RFL-P20QE	RFL-P30QS	RFL-P30Q	RFL-P50QB	RFL-P60Q	RFL-P70Q	RFL-P100Q
Output Power	20W	20W	30W	30W	50W	60W	70W	100W
Beam quality M ²	≤ 1.5	≤ 1.5	≤ 1. 6	≤ 1.5	≤ 1. 6	≤ 1. 6	≤ 1. 6	≤ 1. 6
Pulse repetition frequency	40-60 kHz	30-60 kHz	40-60 kHz	30-60 kHz	50-100 kHz	55-100 kHz	20-400 kHz	20-200 kHz
Laser wavelength	1064 ± 5
Output power stability	< 3%							< 5%
Design Life	Approximately 100,000 working hours (Non-lifetime )
Marking range	100 ~ 300mm (optional range)
Marking depth	≤ 1 mm (depending on power and time)
Marking speed	≤ 10000 mm/s
Repetition accuracy	± 0. 002
Minimum line width	0.1 mm
Minimum character height	0.15 mm
Cooling mode	Built-in air cooling
System power supply	500W/220V/50Hz (110V can be connected)
Temperature, humidity	0 ~ 40 °, 30% ≤ RH ≤ 85%, air conditioner shall be installed when it is used beyond the range
Oil mist	Not Allowed
Operating System	Windows Operating System
File Format	All fonts/fonts in the WINDOWS operating system font library (standard USB input)
Exterior dimension	800X600X1400 mm
Packing size	860X730X1050 mm
Weight of the whole machine	About 75kg

Scope of application
